100GBASE QSFP28

The OPWAY 100G QSFP28 series optical transceiver include SR4, PSM4, CWDM4, LR4, ER4 and other series. This series of optical transceivers adopt LC or MPO interface, with low power consumption, small size, high speed characteristics, is conducive to the data center to increase capacity, improve ports density and reduce power consumption. It is mainly used in 100G data center internal network, data center interconnection, metro network and other environments.


While providing high-quality products for optical communications, it promises the following terms of service：

1. Provide the factory inspection qualification report of the product.
2. Provide the product specification and test report.
3. After-sales policy with a minimum one-year warranty.
4. During use, if there is a quality problem, after receiving the user's fault information,
    it will respond within 24 hours and solve the problem immediately.
5. Regularly visit customers and accept their suggestions for quality improvement with an open mind.


FeaturesParameter

Hot pluggable QSFP28 MSA form package, QSFP28 MSA compliant

+3.3V power supply

Supports 103.1Gb/s and 112Gb/s aggregate bit rates

4 independent full-duplex channels, Each channel has a maximum bandwidth of 28Gb/s

I2C management interface

<RoHS compliance

Operating temperature range: 0~70°C(Commercial)




100G QSFP28 SR4

OPWAY's OPQE01 is a parallel 100Gb/s Quad Small Form-factor Pluggable (QSFP28) optical module.The QSFP28 full-duplex optical module offers 4 independent transmit and receive channels, each capable of 25Gb/s operation for an aggregate data rate of 100Gb/s on 100 meters of OM4 multi-mode fiber.An optical fiber ribbon cable with an MTP/MPO connector can be plugged into the QSFP28 module receptacle.


100G QSFP28 CWDM4

OPWAY's OPQE02 is a 100Gb/s transceiver module designed for optical communication applications,The module converts 4 input channels of 25Gb/s electrical data to 4 channels of CWDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s optical input into 4 channels of CWDM optical signals and then converts them to 4 output channels of electrical data.The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311 and 1331 nm as members of the CWDM wavelength grid defined in CWDM4 MSA. The high-performance Uncooled CWDM DFB transmitters and high sensitivity PIN receivers provide superior performance for 100-Gigabit Ethernet applications up to 2km links .


100G QSFP28 PSM4

OPWAY's OPQE02-4 is a parallel 100Gb/s Quad Small Form-factor Pluggable (QSFP28) optical module.The QSFP28 full-duplex optical module offers 4 independent transmit and receive channels, each capable of 25Gb/s operation for an aggregate data rate of 100Gb/s on 2km of single mode fiber.An optical fiber ribbon cable with an MTP/MPO connector can be plugged into the QSFP28 module receptacle.


100G QSFP28 LR4

OPWAY's OPQE10 is a 100Gb/s transceiver module designed for optical communication applications compliant to 100GBASE-LR4 of the IEEE P802.3ba and OTU4 4I1-9D1F standard. The module converts 4 input channels of 25Gb/s electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data.The central wavelengths of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58 and 1309.14 nm as members of the LAN WDM wavelength grid defined in IEEE 802.3ba. The high performance cooled LAN WDM DFB transmitters and high sensitivity PIN receivers provide superior performance for 100Gigabit Ethernet applications up to 10km links.


100G QSFP28 ER4 Lite

OPWAY's OPQE40 compliant to 100GBASE-ER4 Lite standard. The module converts 4 input channels of 25Gb/s electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data.The central wavelengths of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58 and 1309.14 nm as members of the LAN WDM wavelength grid defined in IEEE 802.3ba. The high performance cooled LAN WDM transmitters and high sensitivity receivers provide superior performance for 100Gigabit Ethernet applications up to 40km links with FEC.


100G QSFP28 ER4

OPWAY's OPQE40-E compliant to 100GBASE-ER4 standard. The module converts 4 input channels of 28Gb/s electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data.The central wavelengths of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58 and 1309.14 nm as members of the LAN WDM wavelength grid defined in IEEE 802.3ba. The high performance cooled LAN WDM transmitters and high sensitivity receivers provide superior performance for 100Gigabit Ethernet applications up to 40km without FEC.


100G QSFP28 ZR4
OPWAY's OPQE80 compliant to 100GBASE-ZR4 standard. The module converts 4 input channels of 25Gb/s electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data.The central wavelengths of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58 and 1309.14 nm as members of the LAN WDM wavelength grid defined in IEEE 802.3ba. The high performance cooled LAN WDM transmitters and SOA+PIN receivers provide superior performance for 100Gigabit Ethernet applications up to 80km links with FEC .

Why Choose Us：


Advantage

1. Strong manufacturing capability
The existing production capacity is 10 million pieces/year, and there are 10,000+ square meters of workshops for expansion.
Provide OEM/ODM/JDM service for top optical module company in the industry.
Special line production and quality control management for valuable customers.

2. Senior core team
More than 20 years of industrial experience of management team.
More than 15 years of experience of optical communication R&D leading talents and core R&D backbone.
More than 8% revenue is used for continuous R&D investment.

3. Strict quality control
More than 12 years of experience in optical module design, manufacturing.
Compliant with operators and top equipment commodity control requirements.

4. Continuous cost control
Lean production capability and leading automated manufacturing platform.
Long-term OEM services for top companies in the industry, establishing a stable and reliable supply chain and full-process cost management

5. Quick response and customization
Senior process technology team, with years of accumulated product development and manufacturing experience,
can meet customer customization needs.

6. Long-term and stable cooperation ability
￥520 million has been raised, and a new plant of 10,000 square meters in Wuhan is waiting for use.
